Now, COMPASS enables to control the car's central locking system in three ways:
1. COMPASS analog outputs
2. Via CAN using the AUTOSTART module
3. Via CAN using the IGLA system
Details:
1. Control the central lock using COMPASS analog outputs.
When this setting is on, the central lock opens by applying a negative polarity pulse to the green wire, and closes by applying a negative polarity pulse to the yellow wire.
To activate the setting, use the SMS command
1234 set doorlock mode 1.
2. Select a CAN device to control the central lock.
If the car is equipped with the kit including IGLA (1CAN1LIN) and AUTOSTART, the system can be reconfigured to control the central lock via the AUTOSTART module.
To activate the setting, use the SMS command
1234 set doorlock dest
2. New SMS commands of the COMPASS 1.1.18 firmware
1234 set doorlock mode 0 —- control the central lock via CAN.
1234 set doorlock mode 1 — control the central lock by analog.
1234 set doorlock mode? — request the current value of the setting.
1234 set doorlock dest 0 — send central lock control command to the default device.
1234 set doorlock dest 1 — send a command to control the central lock to the immobilizer (IGLA).
1234 set doorlock dest 2 — send a command to control the central lock to the Autostart module.
1234 set doorlock dest? — request the current value of the setting.
To update COMPASS to firmware 1.1.18, send the SMS command
1234 <space> fwupdate (where the first four digits are the password).
